概述
Pysmu专业数据分析工具是一个基于Python的高级数据分析系统，专门用于ADALM1000设备的数据采集、分析和报告生成。该工具提供了全面的统计分析、频域分析、异常检测和专业报告生成功能。
功能特性
高级分析功能
基础统计分析: 均值、标准差、最值、中位数、四分位数等
高级统计指标: 偏度、峰度、变异系数、信噪比、总谐波失真等
频域分析: 功率谱密度、主频分量、带宽分析
稳定性分析: 滑动窗口统计、趋势分析
异常检测: Z-score和IQR方法的异常值检测
功率分析: 瞬时功率、视在功率、功率因数、阻抗计算
专业可视化
时域信号对比图: 双通道电压波形显示
功率谱密度图: 频域特性分析
统计分布直方图: 数据分布可视化
稳定性分析图: 滑动窗口统计趋势
异常检测图表: 异常率对比分析
关键指标仪表盘: 综合评估表格
多格式输出
CSV数据文件: 原始数据和分析结果
PNG高清图表: 300 DPI专业图表
PDF综合报告: 包含封面、图表、数据表格和原始数据
JSON汇总报告: 机器可读的分析结果
安装要求
必需依赖
pip install numpy pandas matplotlib scipy pysmu
系统要求
-
Python 3.7+ -
Windows/Linux/macOS -
ADALM1000设备及驱动 -
libsmu C++库
使用方法
基本使用
# 进入示例目录
cd c:UsersAdministratorDownloadslibsmu-masterbindingspythonexamples
# 运行专业分析工具
python professional_analysis_english.py
程序流程
-
设备检测: 自动检测连接的ADALM1000设备 -
设备配置: 配置通道模式和目标值 -
数据采集: 采集指定数量的样本数据 -
数据分析: 执行全面的统计和频域分析 -
结果保存: 生成CSV、PNG、PDF和JSON文件 -
报告生成: 创建专业的分析报告
参数控制
主要可配置参数
1. 采样参数
# 在 run_professional_analysis() 方法中
sample_count = 2000 # 采样数量 (默认: 2000)
sample_rate = 100000 # 采样率 (默认: 100kHz)
2. 通道配置
# 通道A配置 (电压源模式)
target_voltage_a = idx % 6 # 目标电压 (0-5V)
dev.channels['A'].mode = Mode.SVMI # 源电压测电流模式
# 通道B配置 (电流源模式)
target_current_b = 0.05 # 目标电流 (默认: 50mA)
dev.channels['B'].mode = Mode.SIMV # 源电流测电压模式
3. 分析参数
# 稳定性分析窗口大小
window_size = 100 # 滑动窗口大小 (默认: 100)
# 异常检测阈值
threshold = 3 # Z-score阈值 (默认: 3)
# 频域分析参数
fundamental_freq = None # 基频 (自动检测)
4. 输出控制
# 输出目录
output_dir = "analysis_results" # 默认输出目录
# 图表分辨率
dpi = 300 # 图表DPI (默认: 300)
# 显示样本数
display_samples = 1000 # 图表显示的样本数 (默认: 1000)
自定义配置示例
# 创建自定义分析器
analyzer = ProfessionalAnalyzer(output_dir="my_analysis")
# 修改采样参数
# 在 run_professional_analysis() 中修改:
sample_count = 5000# 增加采样数量
# 修改通道配置
target_voltage_a = 2.5# 设置固定电压
target_current_b = 0.1 # 增加电流到100mA
# 修改分析参数
window_size = 200 # 增加窗口大小
threshold = 2.5 # 降低异常检测阈值
输出文件解读
文件结构
analysis_results/
├── csv_data/
│ ├── device_0_raw_data_YYYYMMDD_HHMMSS.csv
│ └── device_0_analysis_YYYYMMDD_HHMMSS.csv
├── plots/
│ └── device_0_analysis_YYYYMMDD_HHMMSS.png
└── reports/
├── device_0_report_YYYYMMDD_HHMMSS.pdf
└── summary_report_YYYYMMDD_HHMMSS.json
1. 原始数据文件 (raw_data.csv)
|
|
|
|
|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
2. 分析结果文件 (analysis.csv)
|
|
|
|
|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
分析类别说明
Basic_Statistics (基础统计)
-
mean: 平均值 -
std: 标准差 -
min/max: 最小/最大值 -
median: 中位数 -
rms: 均方根值
Advanced_Statistics (高级统计)
-
snr_db: 信噪比 (dB) -
thd: 总谐波失真 (%) -
cv: 变异系数 (%) -
skewness: 偏度 -
kurtosis: 峰度
Frequency_Analysis (频域分析)
-
dominant_frequency: 主频 (Hz) -
bandwidth_3db: 3dB带宽 (Hz) -
total_power: 总功率 (W)
3. PDF报告内容
第一页: 封面和摘要
-
设备信息 (序列号、固件版本、硬件版本) -
测试时间和样本数量 -
关键指标摘要 -
整体质量评估
第二页: 分析图表
-
时域信号对比: 显示双通道电压波形 -
功率谱密度: 频域特性分析 -
电压分布直方图: 统计分布可视化 -
稳定性分析: 滑动窗口统计 -
异常检测结果: 异常率对比 -
关键指标仪表盘: 综合评估表格
第三页: 详细数据表格
-
基础统计参数对比 -
高级统计指标 -
分类整理的数值数据
第四页: 原始数据样本
-
前50个样本的详细数据 -
包含时间戳和双通道测量值 -
总样本数统计信息
4. 图表解读
时域信号图
-
X轴: 时间 (秒) -
Y轴: 电压 (V) -
蓝线: 通道A电压 -
红线: 通道B电压
功率谱密度图
-
X轴: 频率 (Hz) -
Y轴: 功率谱密度 (对数刻度) -
用途: 识别信号频率成分和噪声
稳定性分析图
-
X轴: 窗口索引 -
Y轴: 电压 (V) -
实线: 滑动窗口均值 -
阴影: 标准差范围
异常检测图
-
X轴: 检测方法 -
Y轴: 异常率 (%) -
蓝色: 通道A异常率 -
红色: 通道B异常率
5. 质量评估标准
|
|
|
|
|
|---|---|---|---|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
|
故障排除
常见问题
1. 设备未检测到
Error: No devices detected
解决方案:
-
检查ADALM1000设备连接 -
确认驱动程序已安装 -
验证libsmu库安装
2. 依赖库缺失
Missing dependencies: No module named 'pandas'
解决方案:
pip install pandas scipy matplotlib
3. 数据采集失败
Data acquisition failed: timeout
解决方案:
-
减少采样数量 -
检查设备连接稳定性 -
重启设备和程序
4. 内存不足
解决方案:
-
减少采样数量 ( sample_count) -
减少显示样本数 ( display_samples) -
关闭不必要的程序
性能优化
1. 提高采集速度
# 减少采样数量
sample_count = 1000 # 从2000减少到1000
# 减少分析复杂度
window_size = 50 # 减少窗口大小
2. 提高分析精度
# 增加采样数量
sample_count = 5000 # 增加到5000
# 增加窗口大小
window_size = 200 # 增加窗口大小
3. 减少输出文件大小
# 降低图表分辨率
dpi = 150 # 从300降低到150
# 减少原始数据保存
# 注释掉不需要的CSV保存代码
扩展开发
添加自定义分析
def custom_analysis(self, signal_data):
"""
自定义分析函数
"""
# 添加您的分析逻辑
result = np.custom_function(signal_data)
return {'custom_metric': result}
# 在 advanced_voltage_analysis 中调用
custom_result = self.custom_analysis(voltages)
修改输出格式
# 添加Excel输出
def save_excel_report(self, device_idx, analysis_results):
filename = f"device_{device_idx}_report_{self.timestamp}.xlsx"
# 实现Excel保存逻辑
添加实时监控
# 实时数据流处理
def real_time_analysis(self):
while True:
samples = session.get_samples(100)
# 实时分析逻辑
time.sleep(0.1)
技术支持
联系信息
-
项目主页: libsmu GitHub -
文档: pysmu Documentation -
问题报告: GitHub Issues -
以及联系鄙人（🤣毕竟我写的）
版本信息
-
当前版本: 1.0.0 -
兼容pysmu: ≥1.0.0 -
Python要求: ≥3.7
更新日志
v1.0.0 (2025-8-23)
-
初始版本发布 -
完整的统计分析功能 -
PDF报告生成 -
多格式数据输出 -
专业图表可视化
注意: 本工具仅用于ADALM1000设备的数据分析，使用前请确保设备正确连接并安装相应驱动程序。
写在后面，中文实在是支持不了一点，都是小方格，我搞不定了，所以全英文的版本了：
Font configuration set
pysmu Professional Data Analysis Tool
==================================================
Detected 1 device(s)
Configuring device 0: serial 2032205054383031323130323130323 : fw 2.17 : hw F
Channel A: SVMI mode, target voltage 0V
Channel B: SIMV mode, target current 0.05A
Starting professional data acquisition...
Successfully acquired 2000 samples
============================================================
Device 0 Professional Data Analysis
============================================================
Raw data saved: analysis_resultscsv_datadevice_0_raw_data_20250823_110101.csv
Performing advanced data analysis...
Analysis results saved: analysis_resultscsv_datadevice_0_analysis_20250823_110101.csv
Generating professional charts...
Analysis chart saved: analysis_resultsplotsdevice_0_analysis_20250823_110101.png
这是输出日志
Generating PDF report...
PDF report generated: analysis_resultsreportsdevice_0_report_20250823_110101.pdf
=== Key Analysis Results ===
Channel A - Average Voltage: 0.003477V, SNR: 37.0dB, THD: 0.000%
Channel B - Average Voltage: 5.112401V, SNR: infdB, THD: 0.000%
=== Output Files ===
Raw data: analysis_resultscsv_datadevice_0_raw_data_20250823_110101.csv
Analysis results: analysis_resultscsv_datadevice_0_analysis_20250823_110101.csv
Analysis charts: analysis_resultsplotsdevice_0_analysis_20250823_110101.png
PDF report: analysis_resultsreportsdevice_0_report_20250823_110101.pdf
Professional analysis completed! All files saved in: analysis_results
Summary report saved: analysis_resultsreportssummary_report_20250823_110101.json
